Socket Weld Tee Monel 400 1″ SCH80

Product Overview:

The Socket Weld Tee Monel 400 1″ SCH80 is a high-performance pipe fitting designed for applications requiring excellent corrosion resistance and high strength. Made from Monel 400, a nickel-copper alloy, this socket weld tee is ideal for joining three pipes at a 90° angle in fluid and gas systems. With a 1″ size and a SCH 80 wall thickness, it is suitable for high-pressure applications. The socket weld connection provides a secure and permanent fitting with improved flow capacity compared to other types of fittings.

Material Highlights:

Material: Monel 400

Pressure Rating: SCH 80

Corrosion Resistance: Superior resistance to corrosion in seawater, acids, and other aggressive environments

Temperature Resistance: Operates well in temperatures up to 1000°F (540°C)

Weldability: Excellent weldability, ideal for various welding methods, including TIG and MIG

Standard Compliance: Manufactured according to ASME B16.11 for socket weld fittings

Material Composition (Elemental Content of Monel 400):

Nickel (Ni): 63-70%

Copper (Cu): 28-34%

Iron (Fe): 2.5% max

Manganese (Mn): 2.0% max

Silicon (Si): 0.5% max

Carbon (C): 0.3% max

Sulfur (S): 0.024% max

Aluminum (Al): 0.2% max

Titanium (Ti): 0.2% max

Monel 400 is known for its outstanding resistance to corrosion in a variety of aggressive environments, making it ideal for use in marine, chemical processing, and power generation industries.

Technical Specifications:

Size: 1″

Wall Thickness: SCH 80

Material: Monel 400

Pressure Rating: SCH 80

Temperature Resistance: Up to 1000°F (540°C)

Connection Type: Socket Weld

Standard Compliance: ASME B16.11

Dimensions: Customizable upon request

Key Features:

Socket Weld Design: Provides a strong, permanent connection with a secure, leak-free seal

Corrosion Resistance: Monel 400 offers exceptional resistance to a wide range of corrosive environments, including seawater and acids

High-Temperature Stability: Performs reliably in high-temperature environments, up to 1000°F (540°C)

Excellent Strength: High strength and toughness even at extreme temperatures and pressures

Durability: Long-lasting performance, minimizing maintenance and replacement costs over time

Applications:

Marine and Offshore: Ideal for piping systems exposed to seawater or other corrosive substances

Chemical Processing: Perfect for use in systems exposed to acidic and alkaline conditions

Power Generation: Suitable for high-pressure and high-temperature applications in power plants

Oil & Gas: Used in oil and gas pipelines where corrosion resistance and strength are critical

Aerospace and Marine Industries: Monel 400's properties make it suitable for aerospace and marine applications, including pumps, valves, and heat exchangers

Related Products:

Monel 400 Socket Weld Elbow 1″ SCH80

Monel 400 Socket Weld Coupling 1″ SCH80

Monel 400 Socket Weld Cap 1″ SCH80

Monel 400 Flange 1″ Class 150

Monel 400 Threaded Tee 1″ Class 300

SSM Advantages:

High-Quality Monel 400: We supply Monel 400 fittings designed for superior performance in harsh conditions

Customizable Options: Our socket weld tees are available in different sizes and pressure ratings to suit your needs

Fast Lead Times: We ensure timely delivery of your orders with minimal lead time

Technical Support: Our experts are available to assist you with product specifications and selection

Competitive Pricing: Get high-quality Monel 400 fittings at cost-effective prices

Why Choose Us?

At SSM, we provide top-tier Monel 400 pipe fittings that ensure durability and reliability in challenging environments. Our Socket Weld Tee Monel 400 1″ SCH80 is designed to offer superior performance in high-pressure, corrosive, and high-temperature applications. Contact us today for more information or to place an order!
