EQUAL TEE NB150 SCH120, ASTM A234 WPB

The tee has a nominal bore (NB) size of 150 and a Schedule 120 (SCH120) thickness. Standard dimensions conform to ASME B16.9 or similar standards.

Material Description

The tee is made from ASTM A234 WPB, which is a standard specification for wrought carbon steel and alloy steel pipe fittings for moderate and high-temperature service.

Material Composition

ASTM A234 WPB typically contains:

Carbon (C): 0.30% max

Manganese (Mn): 0.29-1.06%

Phosphorus (P): 0.05% max

Sulfur (S): 0.058% max

Silicon (Si): 0.10-0.35%

Chromium (Cr): 0.40% max

Molybdenum (Mo): 0.15% max

Nickel (Ni): 0.40% max

Copper (Cu): 0.40% max

Vanadium (V): 0.08% max

Mechanical Properties:

ASTM A234 WPB typically exhibits the following mechanical properties:

Tensile Strength: 60,000-85,000 psi

Yield Strength: 30,000-65,000 psi

Elongation: 22% min

 Pipe Fitting Inspection Considerations:

Visual inspection for surface defects such as cracks, porosity, or irregularities.

Dimensional checks to ensure conformity with specifications.

Non-destructive testing (NDT) methods such as radiographic testing or ultrasonic testing to detect internal flaws.

Application Range:

Equal tees with these specifications are commonly used in various industrial applications, including oil and gas, petrochemical, power generation, and construction.

Common Q&A:

Q: Can ASTM A234 WPB fittings be used for high-pressure applications? A: Yes, ASTM A234 WPB fittings are suitable for a wide range of pressure applications, depending on the specific design and wall thickness.

Q: What is the difference between equal tees and reducing tees? A: Equal tees have all three branches of the same size, whereas reducing tees have one branch smaller in size than the other two.

Q: Are ASTM A234 WPB fittings weldable? A: Yes, ASTM A234 WPB fittings are commonly welded using various welding techniques such as stick welding, MIG welding, or TIG welding.

SSM Capabilities:

SSM is capable of manufacturing equal tees with the specified dimensions, material grade, and end configurations. Please feel free to contact us for inquiries or purchases.

If you have any further questions or require assistance regarding the tee with the specified specifications, please don't hesitate to reach out.
